| General | |
| Warm up time | 20 seconds |
| First output speed | 4.3 seconds |
| Continuous output speed | 35 ppm |
| Memory | Standard: 2 GB |
| HDD | 320GB |
| Dimensions (WxDxH) | 587 x 684 x 788 mm |
| Weight | 62 kg |
| Power Source | 220-240 V, 50/60 Hz |
| Paper Handling | |
| Recommended paper size | A3, A4, A5, A6, B4, B5, B6 |
| Paper Input Capacity | Standard: 1,200 sheets ( 2×550 sheets paper tray 1×100 sheets bypass tray ) Maximum: 4,700 sheets ( 2×550 sheets paper tray 1×100 sheets bypass tray 2×1000 sheets LCT 1×1500 sheets side LCT ) |
| Paper Weight | 52-300 |
| Copier | |
| Copying Process | Single laser beam & electro-photographic printing Twin laser beams Electro-photographic printing |
| Multiple Copying | Up to 999 copies |
| Resolution | 600 x 600 dpi |
| Zoom | From 25% to 400% in 1% steps |
| Fax (optional | |
| Circuit | PSTN, PBX |
| Compatibility | ITU-T (CCITT) G3 |
| Resolution | 8 x 3.85 line/mm, 200 x 100 dpi (standard) 8 x 7.7 line/mm, 200 x 200 dpi (standard) 8 x 15.4 line/mm, 16 x 15.4 line/mm, 400 x 400 dpi (with optional SAF memory) |
| Transmission Speed | G3: 2 seconds (200 x 100 dpi, JBIG) G3: 3 seconds (200 x 100 dpi, MMR) |
| Modem Speed | Maximum: 33.6 Kbps |
| Scanner | |
| Scanning Speed | ARDF: Max. 80 originals per minute SPDF: Max. 110 (simplex) / 180 (duplex) originals per minute |
| Resolution | Standard: 100 dpi, 200 dpi, 300 dpi, 400 dpi, 600 dpi Default: 200 dpi |
| Original Size | A3, A4, A5, B4, B5, B6 |
| File formats | TIFF, JPEG,PDF, High Compression PDF, PDF-A |
| Bundled Drivers | Network TWAIN Driver |
| Scan to Email | SMTP (Mail Server) Gateway and TCP/IP, POP, IMAP4 |
| Scan to Folder | SMB, FTP |
| Printer | |
| Printer Languages | Standard: PCL5e, PCL6, PDF Direct, PS3 (Emulation) Option: Adobe PostScript3, Adobe PDF |
| Print Resolution | Maximum 1,200 x 1,200 dpi |
| Interface(s) | Standard: USB Host I/F, Ethernet 10 base-T/100 base-TX/1000 base-T Option: Wireless LAN (IEEE 802.11a/b/g/n), Bluetooth, USB Server for Second Network Interface, Bidirectional IEEE 1284/ECP, USB 2.0 |
| Network Protocols | TCP/IP(IP v4,IP v6) |
| Windows® environments | Windows Vista/7/8/8.1/10, Windows Server/2008/2008 R2/2012/2012 R2 |
| Mac OS environments | Mac OS X v.10.7 or later ( PostScript3 required ) |
| UNIX environments | Sun Solaris, HP-UX, SCO OpenServer, Red Hat Linux, IBM AIX, IBM iSeries/AS/400-using OS/400 Host Print Transform |
| SAP environments | SAP R/3 |
| Ecology | |
| Power Consumption | Maximum: 1,600 W Ready mode: 58.3 W Sleep mode: 0.84 W TEC (Typical Electricity Consumption): 1.4 kW/h |
